Acoustic Mesh
Product data
| Model | Acoustic Resistance (MKS Rrays) | Thickness (um) | Mesh Opening (um) | Open Area (%) | Material |
| AM006aPW | 6 | 40 | 85 | 60 | PET |
| AM006PW | 6 | 65 | 105 | 52 | PET |
| AM008PW | 8 | 175 | 150 | 34 | PET |
| AM009PW | 9 | 50 | 78 | 50 | PET |
| AM010PW | 10 | 108 | 115 | 39 | PET |
| AM015PW | 15 | 45 | 50 | 43 | PET |
| AM020PW | 20 | 65 | 67 | 38 | PET |
| AM025PW | 25 | 50 | 53 | 40 | PET |
| AM032TW | 32 | 49 | 38 | 31 | PET |
| AM042TW | 42 | 49 | 29 | 29 | PET |
| AM045TW | 45 | 120 | 50 | 19 | PET |
| AM047PW | 47 | 52 | 36 | 28 | PET |
| AM050TW | 50 | 50 | 30 | 26 | PET |
| AM065TW | 65 | 58 | 30 | 24 | PET |
| AM075TW | 75 | 51 | 25 | 20 | PET |
| AM080TW | 80 | 55 | 23 | 26 | PET |
| AM090TW | 90 | 128 | 40 | 14 | PET |
| AM095PW | 95 | 60 | 32 | 20 | PET |
| AM145TW | 145 | 72 | 27 | 14 | PET |
| AM160TW | 160 | 62 | 20 | 15 | PET |
| AM260TW | 260 | 63 | 18 | 13 | PET |
| AM410TW | 410 | 64 | 15 | 9 | PET |
| AM600TW | 600 | 65 | 12 | 7 | PET |
| AM1050TW | 1050 | 87 | 10 | 3 | PET |
| AM4000TW | 4000 | 88 | 7 | 2 | PET |
Main Features of GWI Acoustics meshes
Smooth monofilament fiber
High precision and consistency
Flat frequency response over the widest possible range
Efficient protection from dust, metal particles and liquids
Strict airflow control
Halogen-free
Complying with REACH and ROHS
Low moisture absorption thanks to PET polymer
Main Application
